รายละเอียดสินค้า

Capacity : 21m ³

Number of Chamber : 2

Steel Specification : Mild Steel

Discharge, Transfer & Compact : Hydraulic Operated

Weight of Stationary Compactor (Approx.) : 6,500 kg

Dimension of Compactor (L x W x H) : 5,000mm x 2,260mm x1,860mm

Waste Discharge Time : 1.42 m³ per min

Electrical & Control

Discharge Gearmotor : 7.5 kW Motor (IE3)

Compact Gearmotor : 7.5 kW Motor (IE3)

Bin Lifter Gearmotor : 0.75 kW Motor (with brake)

Inlet Hopper Door Gearmotorr : 0.15 kW Motor (with brake)

Discharge Door Gearmotor : 0.15 kW Motor (with brake)

Electrical Voltage for Motor : 3 Phase, 415V, 50Hz, 32 Amp

Control Voltage : 24 V DC

Operation Mode : Automatic / Manual Override
